FT-6103
VISUAL FAULT LOCATOR(15mW)
  • Laser diode design with high concentration. Distance test: 15~20 km
  • Efficient conduction test
  • Constant brightness and flash, 2 section operation. Constant brightness mode: stable display of fiber conduction status. Flash mode: quickly detect the position of fiber break point.
  • 3 types of suitable fiber optic adapters FC/SC/ST, which support2. 5mm fiber optic connectors such as FC/SC/ST
  • Overall length : 180 x 30mm

  • Wavelength : 605nm±10nm
  • Power output : 15mW
  • The level of laser light :  CLASS III
  • Distance test : 15~20Km
  • Battery : AAx 2
  • Applicable connectors :  2.5mm FC/ST/SC Universal connector
  • Overall length : 180 x 30mm
  • Operating temperature :  -10℃~+50℃
  • Storage temperature : -20℃~+60℃
  • Weight : 46g
